CUMARK ES350-F0 VFD - Variable-Frequency-Drive - Max.400W/750W Input=220V

CUMARK ES350-F0 Variable Frequency Drive
MODEL: CU_F0_220V_ES350-F0-0K4G/0K7P-1B
The ES350-F0 is a Single-Phase VFD drive and is ideally suited for the variable control of Light Duty CNC Spindles and many other single phase motors.

Spindle Max. Power Rating: 400W
Supports Power Requirements up to 400W with general use
Support Power Requirement up to 750W with Light use such as normal pumps, simple fans

Small and compact size (131*82*176mm), high cost performance;
Built-in RS485 Modbus,.
Easy operation, optional intelligent LCD keyboard;
16 segments speed control;
Open loop vector control;
Built-in PID function.
Built-in Braking unit;
Built-in Timer, Counter, Comparator, logistic arithmetic unit.
Maximum Speed up to 30,000rpm



Application: ES350 series mini inverter is frequently used in food machinery industries, mechanical drawing, printing machinery, industrial air conditioners, textile machinery, CNC and other equipment, aswell as plastics, chemical, cement, ceramics and other general production line requirements.

Please note that our ES350 does not support CANopen, Profibus.

WHAT IS INCLUDED?

x1 Variable Frequency Drive
x1 Hardware Manual
x1 Firmware Manual

Select the DOCUMENTATION tab below for links to the PDF Catalogues and Manuals...

PRICE INCLUDES FREE WORLDWIDE DELIVERY* , DUTIES & TAXES
